Box: 18 mm multi-layer board with internal reinforcement. Surface treatment: the standard color is black, steel sand spraying process. Protective grating: 1.5mm sound permeable steel plate. Frequency divider: built in passive frequency divider network, modular design.
Box: 18mm multilayer board with internal reinforcement
Surface treatment: the standard color is black, steel sand spraying process
Protective grating: 1.5mm sound permeable steel plate
Frequency divider: built in passive frequency divider network, modular design
Lifting point: professional aluminum Pendant
Input connection point: 2 netrik speakon nl4mp speaker connectors
Unit composition: bass unit：2*10" Voice-coil :65mm Treble unit：1*1.5"Voice-coil:76mm | Frequency response(+/-3dB):55--18 000Hz |
Coverage angle (- 6dB): 100 degrees (horizontal) * 10 degrees (vertical) | Sensitivity：100dB@1W.M |
Maximum sound pressure level：130dB | Standard impedance: 8 ohm |
Input power: 800W (rated) 3200W (peak) | Net size（H * W *D）：275mm*895mm*475mm |
Net weight：（KG）：30 |
